Cable Case - MAC 5000ST to Vivid 5/7 - 9.2 m
Diagnostische Kardiologie
sonstige Kardiologie
GE Healthcare
GE Healthcare
zum Wunschzettel hinzufügen
Im Shop anmelden
Im Shop anmelden
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number


Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Product Overview

The Cable Case - MAC 5000ST to Vivid 5/7 - 9.2 m is a cable that acts as an interface between a Case/Mac device and an ultrasound machine. It is particularly designed to trigger a Vivid 5 or Vivid 7 ultrasound machine. It synchronizes the signals from a Case/8000 or Mac5000ST stress system to a General Electric Vivid 5 or Vivid 7. The 9-pin D connector end acts as the input. The cable is 9.2 meters in length, hence it can cover large distances. The cable is a 300V rated, 24 AWG wire gauge, and twisted pair film/braid shielded cable with 50 conductors with semi rigid Polyvinyl Chloride (PVC) insulation as an outer jacket. It accommodates 24 AWG stranded solid wire standards. These plugs are designed to work with stranded cable and are easy to terminate. The 4-40 screw is the part of the display cable, which is made up of brass material with nickel plating. The cable does not have any hazardous materials. It conforms to the requirements of RoHS standards.

Equivalent Part :

Below is more information on the equivalent parts. Parts without a hyperlink are listed for reference only and are not available for purchase online.

Equivalent partPart Details
