Free Breathing Valve and MOPV Interface Manifold BCG
1504-8505-000
New
Anästhesie
Aespire
GE Healthcare
GE Healthcare
zum Wunschzettel hinzufügen
Im Shop anmelden
Im Shop anmelden
Please select date
Second Opinion Approval Needed

Enter your approval number and submit to add item(s) to cart.

Approval Number

Please enter approval number

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without the
approval number, GE will contact you before your order
can be confirmed for shipment.

Second Opinion Approval Needed

Select your approver's name and submit to add item(s) to your cart

Approver Name

Please Select Approver Name

OR

Don't know your approval number? Call 800-437-1171
Enter opt 1 for the first three prompts, and have your System ID available.

If you add item(s) to cart and submit your order without
selecting an approver, GE will contact you before your order
can be confirmed for shipment.


Product Overview

The Free Breathing Valve and Mechanical Overpressure Valve (MOPV) are provided as parts of the vent engine of the Breathing Circuit Gas (BCG) of a ventilator. The drive gas (O₂ or air) enters the vent engine at a pressure towards the bellows assembly. The ventilator is programmed to supply a specified number of breaths per minute to the patient at a specified pressure. Hence pressure is regulated by a pressure regulator, inspiratory flow control valve and MOPV. MOPVACts as a pressure limit control at third level. It is a redundant mechanical valve and operates irrespective of electrical power. The free breathing valve permits the patient to inhale if patient needs a breath in between the programmed cycles thus ensuring that he/she can spontaneously breathe. It is closed upon mechanical inspiration. The underside of vent engine contains MOPV and free breathing valve interface manifold along with a flapper valve placed in the seat of breathing valve and sealed by O-ring. The manifold forms a mechanical driving force for gases to enter the bellows assembly in a controlled condition.

Kompatible Produkte

Aisys

Aisys

Avance

Avance

Aestiva

Aestiva

Aespire

Aespire

Aespire 7100

Aespire 7100

Aestiva 7100

Aestiva 7100
